FILTRINOV MX - Technical Description of the Filtration Unit

24
TECHNICAL DESCRIPTION OF THE FILTRATION UNIT
2
3
3
6
6
8
8
9
9
2
2
5
5
7
7
1
1
4
4
Filter access lid.
Multi-directional, high-fl ow nozzle.
LED light.
Dual fi lter cartridge housing incl.
2 leaf baskets.
Two suction skimmers.
Massage function air-fl ow control.
Counter-current system switch (pneumatic)
In-ground section containing :
Pumps/Control panel/Optional items.
Removable lid with mechanical lock
3
3
2
2
1
1
4
5
Filter pump
Control panel
Pool light transformer
Water drain opening
Remote control unit
3
2
1
2 Leaf baskets
2 Filter cartridges
2 Skimmers
IN-GROUND SECTION SUBMERGED SECTION
5
2
1
4
3
