▬▬▬▬▬▬▬▬▬▬▬▬▬▬▬▬▬▬▬▬▬▬▬▬▬▬▬▬▬▬▬▬▬ FRESH PASTA
A) Control panel: it is fitted with the control devices necessary to operate the appliance
(see "Description of controls").
B) Bowl: contains the product to knead.
C) Kneader tool: to knead the food products.
D) Bowl lid: it is associated to an interlocking device (microswitch). The appliance stops
when the guard is opened.
E) Extrusion mouth: it can be equipped with various types of moulds depending on the
type of pasta to be made.
F) Electric knife: cuts the pasta (optional for PF25E).
TECHNICAL SPECIFICATIONS
(*) Data indicative, variable depending on type of mould and flour used.
Table 1: Technical data of the appliance
Description
Unit of
measurement
PF25E PF40E
Power kW (Hp) 0.37 (0.5) 0.75 (1)
Electric power supply V/Ph/Hz 230-400V/3/50Hz
Bowl capacity kg 2.5 4
Maximum hourly production (*)
kg/h 8 13
Diameter of extrusion mould mm ø57 ø57
Appliance dimensions (LxSxH) mm 285x540x420÷540 305x600x525÷625
Packaging dimensions mm 700x460x770
Net weight kg 35 48
Type of installation Counter installation
Noise level dB (A) <70
