FIMI X8 MINI User Manual

Remote lights
Short press the power button
Light keeps on
Flash in turn
Fade in and out
Remote status
Check battery level
Not connected to the drone
Pairing or updating the firmware
Connection normal
LED1 LED2 LED3 LED4 Battery level
75%＜ Battery level≤100%
50%＜ Battery level≤74%
25%＜ Battery level≤49%
10%＜ Battery level≤24%
The remote controller beeps to warn
that the battery level is less than 10%.
Light status of remote controller
37

FIMI X8 MINI Specifications

General

Max Flight Time	31 minutes
Camera Resolution	12 MP
Video Resolution	4K at 30fps
Max Speed	16 m/s
Max Transmission Distance	8 km
Dimensions (Folded)	145 x 85 x 56 mm
Dimensions (Unfolded)	200 x 145 x 56 mm
Max Ascent Speed	5 m/s
Max Descent Speed	3.5 m/s
Positioning	GPS + GLONASS
Aperture	f/2.0
ISO Range	100-3200
Gimbal	3-axis
Charging Time	90 minutes
Max Wind Resistance	Level 5
Operating Frequency	5.725-5.850 GHz
Obstacle Avoidance	No
Weight	258 g
Battery Capacity	2400 mAh
