Connector Port Connector Pin RS232 /RS485 RS232 cable PC
Data Converter
RS485B
RS485A
RX+
RX-
7
Press

twice to return to the main menu.
8
Power off the terminal.
9
Plug RS485 cable to data converter then
into terminal and computer.
10
Turn on power and continue to configure
Security (see Security on page 68 for
more details).
In this page you will need to enter the value.
Baud To define the baudrate of the connection.
RS232 Select Yes to enable.
RS485 Select No to disable.
USB Select Yes to enable.
RS485 SINGLE CONNECTION
RX+
RX-
RS232 cable RS485
PC RS232/RS485 Converter Plug Terminal
Data Converter
