17
WHEN ORDERING PARTS, BE SURE TO STATE
SERIAL NUMBER OF MACHINE
B40 MUA2018 Rev A
DISCHARGE HEAD ASSEMBLY
Ref. No. Part No. Description No. Required
1 035115 Discharge Elbow 1
2 035111 Discharge Tube Weldment 1
3 035117 Discharge Head Handle 1
4 035118 Pivot Pin 1
5 035114-01 Discharge Seal - Felt 1
6 035114-02 Discharge Main Seal - Rubber 1
7 035116-03 Head Stop Tubes 2
8 022962 Hair Pin Cotter 1
9 X0420 1/4 in. Bolt 8
10 W04F 1/4 in. Flat Washer 16
11 W04L 1/4 in. Lock Washer 8
12 Y04 1/4 in. Hex Nut 8
13 X05128 5/16 in. Bolt 2
14 Y05 5/16 in. Hex Nut 2
15 W08F 1/2 in. Flat Washer 2
16 W05L 5/16 in. Lock Washer 2
17 W12F 3/4 in. Flat Washer 2
18 Y08J 1/2 in. Jam Nut 1
19 Y08L 1/2 in. Lock Nut 1
20 035024-09 Swivel Spacer 4
21 W05L 5/16 in. Lock Washer 4
22 X0524 5/16 in. Bolt 4
23 W05F 5/16 in. Flat Washer 8
24 035136 Transition Weldment 1
25 035037 O-Ring 1
To Next Page
