21
WHEN ORDERING PARTS, BE SURE TO STATE
SERIAL NUMBER OF MACHINE
B40 MUA2018 Rev A
CONTROL BOX WIRING
Part No. Description No. Required
035128 Control Box Assembly 1
035128W Wiring Harness for 035128 1
035098 Power Pulse Flasher 1
052112 Toggle Switch 1
080526 Toggle Switch Boot 1
FW71584 Idec Timer Relay 1
FW71585 Idec Timer Relay Socket 1
FW71749-02 Relay 1
085212 Ground Cable 1
035127 Battery 1
035073 Electric Clutch 1
035103 Control Box 1
035129 Battery Cable (RED) 1
To Next Page
