10-H Parts Description
Firebird System Range 90/120 - 120/150 White Cased Model
10
SPARE PARTS-BOILER
45
ITEM COMPONENT PART No. Qty
No. per boiler
1 Side Panel L H Side FC03118L 1
2 Side Panel R H Side FC03118R 1
3 Dual Stat IM TLSC 542764 1
4 Top Panel SS0312112 1
4a Flue Trim Plate FC03122 1
4b Conventional Trim Plate FC03123 1
5 Back Panel FS125 - BP-L-04 1
6 Front Panel SS0312012 1
7 Baffle Door FS125 - L-08 1
8 Baffles FS125 - L-09 8
9 Burner Mounting Flange
See Burner Parts Book 1
10 Flue Elbow FS125 - L-30 1
11 Drip Tray FS125 - L-31 1
12 Burner RDB 2 (3513602) 1
13 Snorkel 3”snorkel pipe & jubilee clip 1
14 Instrument Panel FS125 - LS-L-46 1
15 Viewing glass bracket FC 03110 1
15a Viewing glass FC 03111 1
15b Viewing glass gasket P70-L-45 1
16 Flue gas analysis cover FC 03113 1
16a Flue gas analysis cover gasket FC 03114 1
1 Side Panel L H Side SS150 - LH-L-01 1
2 Side Panel R H Side SS150 - RH-L-02 1
3 Dual Stat IM TLSC 542764 1
4 Top Panel SS150 - TP-L-03 1
4a Flue Trim Plate SS150 - FTP-L-03 1
4b Conventional Trim Plate SS150 -CTGP-L-03 1
5 Back Panel SS150 - BP-L-04 1
6 Front Panel SS150 - FP-L-05 1
7 Baffle Door FS150 - L-08 1
8 Baffles FS150 - L-09 8
9 Burner Mounting Flange
See Burner Parts Book 1
10 Flue Elbow FS150 - L-30 1
11 Drip Tray FS150 - L-31 1
12 Burner RDB 3 1
13 Snorkel 3”snorkel pipe & jubilee clip 1
14 Instrument Panel FS150 - LS-L-46 1
15 Viewing glass bracket FC 03110 1
15a Viewing glass FC 03111 1
15b Viewing glass gasket P70-L-45 1
Firebird System Range 90/120 White Cased Model
Firebird System Range 120/150 White Cased Model
