The LEDs - Strobe and Status
6
The LED lens houses the 3 LEDs - one
Status LED (GREEN) in the centre and
two Strobe LEDs (RED) either side.
The Strobe LEDs will flash when in a
fire condition or if a major fault has
occurred.
The Status LED will flash according to
the Deafgard status.
If Deafgard is turned On, under normal
conditions the Status LED will flash
green once every 15 seconds.
The Status LED will flash red once
every 8 seconds if there is a minor fault,
such as a Pillow Pad error when the
LCD will also display ‘PAD’.
If a major fault occurs the Status LED
will flash RED once every 4 seconds.
This will happen if Deafgard batteries
become critically low. With this fault
condition, at 15 second intervals, the
Strobe LEDs will flash and the Pillow
Pad will vibrate for 4 seconds.
The Status LED will illuminate red
throughout a fire alarm condition.
