FireMagic Aurora Owner's Manual

REV 8 - 1401220800
L-C2-294
5
REPLACEMENT PARTS LIST (cont.)
A430s
Item Description Part No. Qty.
1.
Stainless cooking grid (set of 2) 3542-S-2 1
2.
Flavor grid (set of 2) 3063-S-2 1
3.
Main burner 3042-50 2
4.
Infrared burner (optional)‡ 3051 1
5.
Oven lid 23729-53 1
6.
Warming rack* 3672S-M 1
7.
Back burner* 24130-11 1
8.
Back burner cover* 24148-010 1
9.
Patio base w/ hardware
†
24330-31 1
or
In-ground base w/ hardware
†
24330-32 1
10.
Rotisserie motor* 3600-02 1
11.
Rotisserie rod* 3603-30 1
12.
Rotisserie knob* 24187-16 1
13.
Meat holder (pair)* 3613 1
14.
Counterbalance* 3620E 1
15.
Grid lifter 3519 1
16.
Convertible regulator PR-4 1
17.
Valve manifold w/ back burner 24130-22 1
or
Valve manifold w/o back burner 24130-28 1
18.
Control panel w/ back burner 24130-45 1
or
Control panel w/o back burner 24130-46 1
19.
Small knob* 3016 1
20.
Large knob 3015 2
21.
Digital thermometer 24180-12 1
22.
Meat probe 24187-14S 1
A430s
Item Description Part No. Qty.
23.
Drip tray 3084 1
24.
Drip tray liner (set of 4) 3557 1
25.
Rigid shelf 24330-017 2
26.
Patio mount hardware kit
(if applicable)
24330-25 1
27.
Timer valve (3 hour) 3090 1
or
Timer valve (1 hour) 3092 1
28.
Propane regulator / hose assy. 5110-07 1
or
Natural Gas QD hose ‡ 5110-03 1
29.
Wire harness assembly‡ 24177-26 1
30.
Back burner electrode*‡ 4199-70 1
31.
Electrode & collector box assy‡ 3199-45 2
32.
Ignitor module 3199-44 1
33.
Natural gas orifi ce(s)‡ 3001-42-2 1
34.
Natural back burner gas orifi ce(s)‡ 3001-52-1 1
35.
Propane gas orifi ce(s)‡ 3001-54-2 1
36.
Propane back burner gas
orifi ce(s)‡
3001-59-1 1
37.
Fire Magic
®
cookbook‡ 3595 1
38.
Thermometer wire harness‡ 24177-25 1
39.
Wire harness extension 24177-27 1
40.
Power supply box w/ connector 24177-11 1
41.
12V / 10 watt halogen light bulb ‡ 24187-15 2
42.
Light lens ‡ 24187-26 2
43.
Lamp assembly ‡ 24187-28 2
44.
Light switch
24182-46
1
* If equipped
†
For replacement only (not conversion)
‡ Not shown
Specifi cation Value
Main Burner
BTU per burner pair
25,000 x 2
Natural gas orifi ce
#42
(2.375 mm)
Propane gas orifi ce
#54
(1.397 mm)
Infrared Burner (if equipped)
BTU per burner
18,000
Natural gas orifi ce
#46
(2.057 mm)
Propane gas orifi ce
#56 (1.181 mm)
Specifi cation Value
Backburner (if equipped)
BTU per burner
12,500
Natural gas orifi ce
#52 (1.613 mm)
Natural air shutter
5/8-inch gap
Propane gas orifi ce
#59 (1.041 mm)
Propane air shutter
7/16-inch gap
Power supply rating
120VAC / 0.5A / 60Hz
Oven lights rating 12V / 10 watt halogen bulb
PRODUCT DATA TABLE
Table 1 - Product Data Table

FireMagic Aurora Specifications

General

Grill Type	Built-In
Ignition System	Electronic
Material	Stainless Steel
Cooking Grid Material	Stainless Steel
Fuel Type	Natural Gas or Propane
Warranty	Lifetime on Stainless Steel Components
