FireMagic Aurora - In-Ground Post Grill Dimensions Table

REV 8 - 1401220800
L-C2-294
7
Height* Width Depth
Floor to top
(with oven)
Floor to
top of
shelf
(L)
Floor to
bottom of
extension
below
ground
(M)
Left to right Front to back
Post
(N)
(with shelves)
Post
(R)
Maximum
outer
(S)
Open
(J)
Closed
(K)
Up
(O)
down
(P)
1 Up /1 Down
(Q)
57" 50” 37” 18” 5
1
/2” 55
3
/4" 35
1
/4" 45
1
/2"5
1
/2” 25
3
/4"
*Note: Height dimensions are approximate from ground level once installed.
IN-GROUND POST GRILL DIMENSIONS TABLE
Fig. 7-1
Ground level
MODEL SPECIFICATIONS (cont.)
S
L
O
K
P
J
Q
Ground level
N
M
R
