5. ASSEMBLY INSTRUCTIONS
1 Carefully remove all packaging.
2 The firebox front when installed must be flush with the finished fireplace
surround and on a level base of the same height as the finished floor
protector. This may be achieved by using a concrete mix to level the base.
3 Slide the firebox into the opening so that the outer casing return folds are
flush with the finished fireplace surround.
4 it is important to anchor the fire box down in case of movement. Restraint
points are provided through the fires two front legs.
5 Install Flue as per instructions on page 8 and 9.
6 Now that the firebox and flue are in position,
place 25mm white kaowool
blanket (supplied) on top of casing.
7 As this fire sources its combustion air from the chimney cavity/enclosure,
the fire MUST be sealed around the front between the casing and the
masonry. This is achieved by packing the yellow ISB insulation
supplied between the casing and the masonry at the FRONT ONLY to
maximum depth of 80mm. As shown on pages 10 and 11.
8
Assemble and fit the fascia as per instructions on the relevant pages 27-39.
NOTE: In the case of some insert fires into existing masonry fireplaces it may be
necessary to install additional adventitious ventilation into the chimney cavity as
per AS/NZ 2918 3.4.1.2 to assist air flow into the fire. This ventilation should not
be taken/drawn from the room that the fire is installed in.
