INTRODUCTION FIREPOWER FP-125,135,165
Introduction 2-3 Manual 0-5123
2.06 Volt - Amp Curves
FP-125 FIREPOWER Vin=115V 60Hz
5.0
10.0
15.0
20.0
25.0
30.0
35.0
0 10 20 30 40 50 60 70 80 90 100 110 120 130 140
OUTPUT VOLTAGE
Art # A-09076
Figure 2-1: Volt/Amp curves of the FirePower 125
FP-135 FIREPOWER Vin=115V 60Hz
0
5
10
15
20
25
30
35
0 10 20 30 40 50 60 70 80 90 100 110 120 130
OUTPUT CURRENT
OUTPUT VOLTAGE
Art # A-09077
Figure 2-1: Volt/Amp curves of the FirePower 135
