OPERATION FIREPOWER FP-125, 135, 165
Operation 4-3 Manual 0-5123
LOW1
2
COARSEFINE
HIGH
FP-125
v
RATED OUTPUT
VOLTS 15
AMP 110
DUTY CYCLE 13%
MAX OCV 30
AMP RANGE 40-110
CSA
21
60
40%
30
40-110
120V Wire Feed Welder
Welds 24 gauge to 3/16"(4.8mm) Mild Steel
12
11
9
7
6
5
3
2
1
4
8
10
Art # A-09065
3
13
Figure 4-1: FirePower FP-125 Controls
FP-135
RATED OUTPUT
VOLTS 18
AMPS 120
DUTY CYCLE 20%
MAX OCV 32
AMP RANGE 39-120
CSA
21
60
60%
32
39-120
120V Wire Feed Welder
Welds 24 gauge to 1/4"(6.4mm) Mild Steel
12
11
9
7
6
5
3
2
1
4
8
10
Art # A-09066
13
Figure 4-2: FirePower FP-135 and 165 Controls
