Firepower FP-18 - Appendices; Leads Connections

Service Manual 0-2692 23 Firepower FP-18 Plasma Cutter
Torch Leads Assembly
Strain Relief Nut
Strain Relief
1" Clearance
Strain
Relief
Torch Lead Faston Connector (Red)
(Connect to Bottom Resistor)
2-Pin Connectors
Torch
Lead
Faston Connector
to CD Coil
90˚White
Nylon Fitting
Brass Torch
Lead Fitting
A-02009
Nylon Nut
Front Panel
Hole Location
Note: Do not remove strain relief from torch lead.
APPENDIX I - LEADS CONNECTIONS
