FIREWOLF FW-C2Z - Fig.4: FW-C4 EZ Module Mounting Locations

(MODEL FW-DACT)
DIALER MODULE
(MODEL FW-RPM)
POLARITY REVERSAL AND
CITY TIE MODULE
M/F HEX SPACER
#6-32 x 7/8"
SCREW
#6-32 x 1/4"
DISPLAY
PLATE
BACKBOX
ZONE ADDER
MODULE
(FW-EZM4)
MAIN FIRE
ALARM
MODULE
RELAY MODULE
(NOTE 1)
NOTES:
1. RELAY MODULE MAY BE FW-RB4 OR FW-4B8
2. ONLY ONE OF FW-DACT OR FW-RPM MAY BE INSTALLED
Page 11 of 36
Fig.4: FW-C4EZ Module Mounting Locations
