Page 34 of 36
APPENDIX "C" - MODULE SPECIFICATIONS and FEATURES
Fire Alarm Control Panel (FW-C2Z) Fire Alarm Control Panel (FW-C4EZ)
General: In smaller Enclosure ... General: In larger Enclosure ...
M 1 supervised Style B (Class B) Initiating Circuit; configurable M 4 supervised Style B (Class B) or 2 Style D (Class A) Initiating
(Normal or Verified). [Compatibility ID “A”] Circuits; configurable. [Compatibility ID “A”]
Power Limited: 26VDC, 3 mA standby, 1.5Vp-p ripple, 50 Power Limited: 26VDC, 3 mA standby, 1.5Vp-p ripple, 50
mA max. (alarm) mA max. (alarm)
M 2 Style Y/Z (Class A/B) Notification Circuits; configurable as M 2 Style Y/ Z (Class A/B) Notification Circuits; configurable as
strobes or audibles. strobes or audibles.
Power Limited: 24 VDC unfiltered Power Limited: 24 VDC unfiltered
1.7 A @ 49C per Circuit (2.4 A Total) 1.7 A @ 49C per Circuit (5A Total)
M 2 supervised Style B (Class B) or 1 Style D (Class A) Initiating M One FW-EZM4 Zone Expansion may be added.
Circuits; configurable (Normal or Verified). M Initiating Circuit Disconnect Switches.
[Compatibility ID “A”] M Optional FW-DACT or City Tie Adder.
M Initiating Circuit Disconnect Switch. M Optional FW-RB4 / FW-RB8 Relay Module.
M Optional FW-DACT or City Tie Adder. M Resettable 4-Wire Smoke Detector Power Supply.
M Optional FW-RB4 / FW-RB8 Relay Module. Power Limited: 28VDC, 100mA max, 1.5Vp-p ripple
M Resettable 4-Wire Smoke Detector Power Supply. M Aux Power Supply.
Power Limited: 28VDC, 100mA max, 1.5Vp-p ripple Power Limited: 24VDC, 300mA max, unfiltered
M Aux Power Supply. for RTI or Remote Annunciators
Power Limited: 24VDC, 300mA max, unfiltered M 1 RS-485 Connection for up to 3 FW-RB8 Remote
for RTI or Remote Annunciators Annunciators.
M Auxiliary relays: (resistive loads) M Auxiliary relays: (resistive loads)
Common Alarm: Form C, 1Amp, 28VDC Common Alarm, Supervisory, Trouble
Common Trouble: Form C, 1Amp, 28VDC All are Form C, 1Amp, 28VDC
M Micro-controller Based Design. M Micro-controller Based Design.
M DIP Switch Configurable. M DIP Switch Configurable.
M Walk-Test function. M Walk-Test function.
Electrical ratings: Electrical ratings:
M AC Line Voltage: 102 to 132 VAC. M AC Line Voltage: 102 to 132 VAC.
2 Amps (primary, transformer inline fuse) 2.5 Amps (Uses 4A circuit breaker)
M Pwr Supp. ratings: 2.75 Amps. max. (secondary) M Pwr Supp. ratings: 6 Amps. max. (secondary)
M For Notification Circuits: 24VDC unfiltered M For Notification Circuits: 24VDC unfiltered
2.40 Amps. max. 5 Amps. max.
M Battery: 24VDC, Gel-Cell/Sealed Lead-Acid M Battery: 24VDC, Gel-Cell/Sealed Lead-Acid
Charging capability: 4 to 6.5 AH batteries Charging capability: 10 to 24 AH batteries
Fuse on Main Board: 10 Amps. Fuse on Main Board: 10 Amps.
M Current Consumption: Standby: 110 mA, Alarm: 220 mA M Current Consumption: Standby: 110 mA, Alarm: 220 mA
Fire Alarm Control Panel (FW-C4Z) Zone Expansion Module (FW-EZM4)
General: Same as FW-C2Z, plus ... M May be added to FW-C4EZ.
M 4 supervised Style B (Class B) or 2 Style D (Class A) Initiating M 4 supervised Style B (Class B) or 2 Style D (Class A) Initiating
Circuits; configurable (Normal or Verified, and for Style B there Circuits; configurable. [Compatibility ID “A”]
may be one Waterflow and one Supervisory). Power Limited: 22VDC, 3 mA standby, 1.5Vp-p ripple, 50
[Compatibility ID “A”] mA max. (alarm)
M Optional FW-RB4 or FW-RB8 Relay Module. M 2 Style Y or Z (Class B or A) Notification Circuits; configurable
M 1 RS-485 Connection for up to 3 FW-RB8 Remote as strobes or audibles.
Annunciators. Power Limited: 24 VDC unfiltered, 1.7A @49C per Circuit
M Auxiliary relays: (resistive loads) M Current Consumption: Standby: 45 mA, Alarm: 120 mA
Common Alarm, Supervisory, Trouble
All are Form C, 1Amp, 28VDC 8 Zone Remote Annunciator (FW-RB8)
DACT / Dialer Module (FW-DACT) M Current Consumption: Standby: 35 mA, Alarm: 90 mA
M DACT - “Digital Alarm Communicator Transmitter”
Using Ademco Contact ID and SIA-DCS Protocols.
M Current Consumption: Standby: 45 mA, Alarm: 120 mA
Polarity Reversal and City Tie Module (FW-RPM)
M Supervised City Tie Not Power Limited
24VDC unfiltered, 210 mA max., Trip coil: 14 ohms
M Polarity Reversal Power Limted
24VDC open, 12VDC @ 3.5 mA, 8 mA max. (shorted)
M Current Consumption: Standby: 35 mA, Alarm: 300 mA System Model: SERIES FW-CZ, Fire Alarm Control Panel
Model: FW-RB4 / FW-RB8 Relay Module Protected Premises (using FW-DACT or FW-RPM), Central Station
M Four or Eight Relays: Form C, 1A (resistive), 28 VDC per Protected Premises (using FW-DACT).
contacts Type of Service: A, M, WF, SS (SS is only Local or with DACT)
M Each individual relay can be: Type of Signalling: Non-Coded
Relay per Zone, Common Alarm, Common Supervisory Applicable Standards: NFPA 70 and 72, UL-864, ULC S-524, ULC
M Current Consumption: Standby: 5 mA, Alarm: 160 mA S-527
M RS-485 Interface, up to 3 per FA-200 Panel.
System Type: Local, Auxiliary (using FW-RPM), Remote Station
