WIRING DIAGRAM FOR DEFAULT MESSAGES
24 26 28
25 27 29
LOW OIL
TEMP
LOW OIL
PRESS
LOW ATOMIZER
MEDIA
LOW GAS
PRESSURE
HIGH GAS
PRESSURE
L1
3
P
GAS OIL
31 33 35
30
32 34
HIGH
PRESS
AIR
FLOW
AUX
LIMIT
HIGH
TEMP
AUX
LIMIT
AUX
LIMIT
#4
#5
#6
23
LOW
WATER
HIGH
WATER
13
AUX
LIMIT
#1
AUX
LIMIT
#3
AUX
LIMIT
#2
20 22
21
OPERATOR
CONTROL
L2
TO L2 ON E110
L2
TO L2 TERMINAL ON 60-1950 WIRING BASE NOTE: All existing wiring on terminals not shown
will be undisturbed when the E300 is installed.
60-1950 WIRING BASE
60-1386-2 or 60-1466-2 WIRING BASE FOR FLAME MONITOR
FUEL VALVE
END SWITCH
