First Alert FA168CPS Programming Guide

–
4
–
NOTE: Entry of a number other than one specified will give unpredictable results.
For fields *43 thru *46:
Enter 0–9; #+11 for B; #+12 for C; #+13 for D; #+14 for E; #+15 for F. Enter
[
✱
]
as the fourth digit if a 3-digit account number (for 3+1 dialer
reporting format) is used. Enter 0 as the first digit of a 4-digit account number for Nos. 0000-0999. Exit field by pressing
✱
if only 3 digits are used. E.g., For Acct.
B234
, enter:
#+11| 2 | 3 | 4
✱
43
PARTITION 1 PRIMARY ACCT. No.
| | | / | | | | |
Enter 4 or 10 digits, depending on selection in *48 Report
Format. See box above. To clear entries, press
*
43
*.
[FFFF]
✱
44
PART. 1 SECONDARY ACCT. No.
| | | / | | | | |
Enter 4 or 10 digits, depending on selection in *48 Report
Format. See box above. To clear entries, press
*
44
*
. [FFFF]
✱
45
PARTITION 2 PRIMARY ACCT. No.
| | | / | | | | |
Enter 4 or 10 digits, depending on selection in *48 Report
Format. See box above. To clear entries, press
*
45
*
. [FFFF]
✱
46
PARTITION 2 SECONDARY ACCT.
No.
| | | / | | | | |
Enter 4 or 10 digits, depending on selection in *48 Report
Format. See box above. To clear entries, press
*
46
*
. [FFFF]
✱
47
PHONE SYSTEM SELECT
[1]
If Cent. Sta.
IS NOT
on a WATS line: 0=Pulse; 1=Tone;
if Cent. Sta.
IS
on a WATS line: 2 = Pulse; 3 = Tone
✱
48
REPORT FORMAT
[77]
primary secondary
0 = 3+1, 4+1 ADEMCO L/S STANDARD
1 = 3+1, 4+1 RADIONICS STANDARD
2 = 4+2 ADEMCO L/S STANDARD
3 = 4+2 RADIONICS STANDARD
5 = 10-digit ADEMCO CONTACT ID® REPORTING
6 = 4+2 ADEMCO EXPRESS
7 = 4-digit ADEMCO CONTACT ID® REPORTING
8 = 3+1, 4+1 ADEMCO L/S EXPANDED
9 = 3+1, 4+1 RADIONICS EXPANDED
✱
49
SPLIT/DUAL REPORTING
[0]
0 = Standard/backup reporting only (all to primary)
Primary Phone No. 2nd Phone No.
1 = Alarms, Restore, Cancel Others
2 = All except Open/Close, Test Open/Close, Test
3 = Alarms, Restore, Cancel All
4 = All except Open/Close, Test All
5 = All All
✱
50
BURGLARY DIALER DELAY
[2]
0 = no delay UL: must be “0”
1 = 15 seconds SIA Installations: delay
2 = 30 seconds must be minimum of
3 = 45 seconds 30 seconds
✱
53
SESCOA/RADIONICS SELECT
[0]
0 = Radionics (0-9, B-F)
1 = SESCOA (0-9 only reporting)
Select “0” for all other formats.
✱
54
DYNAMIC SIGNALING DELAY
[0]
Select delay from 0 to 225 secs, in 15-sec increments.
0 = no delay (both signals sent), 1 = 15 secs,
2 = 30 secs, etc.
UL: Grade AA must be “0;” Grade A must be “15” max
✱
55
DYNAMIC SIGNALING PRIORITY
[0]
0 = Primary Dialer first; 1 = Long Range Radio first.
For UL Commercial Burglary installations that use a
DACT and LRR, this field must be “0”.
✱
56, *57, *58
MENU MODES
These are Menu Mode commands, not data fields, for Zone Programming, Function
Key Programming, and Expert Mode Zone Programming respectively. See page 2 and
their respective sections in the Installation and Setup Guide for procedures.
TO PROGRAM SYSTEM STATUS, & RESTORE REPORT CODES (
✱
59 thru *68, *70 thru
✱
76, and
✱
89):
For 3+1 or 4+1 Standard Format:
Enter a code in the
first
box: 1–9, #+10 for 0, #+11 for B, #+12 for C, #+13 for D, #+14 for E, #+15 for F.
A 0 (
not
#+10) in the
first
box will disable a report. A 0 (
not
#+10) in the
second
box will result in automatic advance to the next field.
For Expanded or 4+2 Format:
Enter codes in
both
boxes (1st and 2nd digits) for 1–9, 0, or B–F, as described above.
A 0 (
not
#+10) in the
second
box will eliminate the expanded message for that report. A 0 (
not
#+10) in
both
boxes will disable the report.
For Ademco Contact ID® Reporting:
Enter any digit (other than 0) in the
first
box, to enable zone to report (entries in the
second
boxes are ignored).
A 0 (
not
#+10) in the
first
box disables the report.
UL: see installation instructions for requirements
SYSTEM STATUS REPORT CODES (
✱
59–
✱
68)
✱
59
EXIT ERROR REPORT CODE
[0] See box above.
✱
60
TROUBLE REPORT CODE
| [00] See box above.
✱
61
BYPASS REPORT CODE
| [00] See box above.
✱
62
AC LOSS REPORT CODE
| [00] See box above.
✱
63
LOW BAT REPORT CODE
| [00] See box above.
✱
64
TEST REPORT CODE
| [00] See box above. Use Scheduling mode to set periodic test reports,
or use the following key commands:
Each mode sets schedule 32 (FA168CPS) or installer code +[#] + [0] + 0 = test report sent every 24 hours
schedule 08 (FA148CP) to the stated installer code +[#] + [0] + 1 = test report sent once per week
repeat option; first test report sent 12 hours after command. installer code +[#] + [0] + 2 = test report sent every 28 days
