6
–
✱
92
PHONE LINE MONITOR ENABLE
UL: see Inst. Instructions for requirements
[0,0]
1 2
NOTE:
Output Device must
either be programmed to be
STOPPED in field
✱
80 or
STOPPED by Code + # + 8 +
output number.
Entry 1:
: 0 = disabled, 1-15 = 1 min - 15 min
(#+10 = 10 min; #+11 = 11 min; #+12 = 12 min;
#+13 = 13 min; #+14 = 14 min; #+15 = 15 min)
Entry 2
:
0 = Keypad display when line is faulted
1 = Keypad display plus keypad trouble sound
2 = Same as “1”, plus programmed output device
STARTS. If either partition is armed, external
sounder activates also.
✱
93
No. OF REPORTS IN ARMED PERIOD
PER ZONE (Swinger Suppression)
[1]
0 = Unlimited Reports; 1 = 1 report; 2 = 2 reports
UL: must be “0”
SIA Installations: Must be set for option 1 or 2.
DOWNLOAD INFORMATION (
✱
94,
✱
95)
✱
94
DOWNLOAD PHONE No.
| | | | | | | | | | | | | | | | | | |
Enter up to 20 digits, 0–9; #+11 for '
✱
'; #+12 for '#'; #+13 for a 2-second pause. Do not fill unused
spaces. If fewer than 20 digits, exit field by pressing
✱
. To clear entries from field, press
✱
94
✱
.
UL: downloading may be performed only if a technician is at the site.
✱
95
RING COUNT FOR DOWNLOADING
[15]
NOTE:
Do not enter “0” if using
FA4285/FA4286 Phone
Module.
0 = Disable Station Initiated Download;
1–14 = number of rings (1–9, # +10 =10, # +11 =11,
# +12 =12, # +13 =13, # +14 =14);
15 = answering machine defeat (# +15 =15).
∗
96,
∗
97
INITIALIZE/RESET DEFAULTS
These are commands, not data fields. See page 2.
∗
98, *99
EXIT COMMANDS
These are commands, not data fields. See page 2.
PAGER OPTIONS (
✱
160-
✱
172)
✱
160
PAGER 1 PHONE No.
| | | | | | | | | | | | | | | | | | |
Enter up to 20 digits. 0–9; #+11 = '
✱
'; #+12 = '#'; #+13 = 2-second pause.
✱
161
PAGER 1 CHARACTERS
| | | | | | | | | | | | | | |
Enter the optional prefix characters, up to 16 digits.
0–9; #+11 = '
✱
'; #+12 = '#'; #+13 = 2-second pause.
✱
162
PAGER 1 REPORT OPTIONS
Part. 1 Part. 2 common
[0,0,0]
For each partition, select from the following options:
0 = no reports sent
1 = Open/closes all users
4 = All alarms and troubles
5 = All alarms / troubles, and open/closes for all users
12 = Alarms / troubles for zones entered in zone list 9
13 = Alarms / troubles for zones entered in zone list 9,
and open/closes for all users
✱
163
PAGER 2 PHONE No.
| | | | | | | | | | | | | | | | | | |
Enter up to 20 digits. 0–9; #+11 = '
✱
'; #+12 = '#'; #+13 = 2-second pause.
✱
164
PAGER 2 CHARACTERS
| | | | | | | | | | | | | | |
Enter the optional prefix characters, up to 16 digits.
0–9; #+11 = '
✱
'; #+12 = '#'; #+13 = 2-second pause.
✱
165
PAGER 2 REPORT OPTIONS
[0,0,0]
Part. 1 Part. 2 common
See field *162 for reporting options. Select for each
partition (use zone list 10 if using options 12 or 13).
✱
166
PAGER 3 PHONE No. | | | | | | | | | | | | | | | | | | |
Enter up to 20 digits. 0–9; #+11 = '
✱
'; #+12 = '#'; #+13 = 2-second pause.
✱
167
PAGER 3 CHARACTERS | | | | | | | | | | | | | | |
Enter the optional prefix characters, up to 16 digits.
0–9; #+11 = '
✱
'; #+12 = '#'; #+13 = 2-second pause.
✱
168
PAGER 3 REPORT OPTIONS
0,0,0]
Part. 1 Part. 2 common
See field *162 for reporting options. Select for each
partition (use zone list 11 if using options 12 or 13).
✱
169
PAGER 4 PHONE No. | | | | | | | | | | | | | | | | | | |
Enter up to 20 digits. 0–9; #+11 = '
✱
'; #+12 = '#'; #+13 = 2-second pause.
✱
170
PAGER 4 CHARACTERS
| | | | | | | | | | | | | | |
Enter the optional prefix characters, up to 16 digits.
0–9; #+11 = '
✱
'; #+12 = '#'; #+13 = 2-second pause.
✱
171
PAGER 4 REPORT OPTIONS
[0,0,0]
Part. 1 Part. 2 common
See field *162 for reporting options. Select for each
partition (use zone list 12 if using options 12 or 13).
✱
172
PAGER DELAY OPTION FOR ALARMS
[3]
0 = none, 1 = 1 minute, 2 = 2 minutes, 3 = 3 minutes
This delay is for ALL pagers in the system.
To Next Page
