FO4- 1000mS (1 sec): When using POC SV 30 the CMX will provide a negative output (on) to activate
the hazard light circuit. 1000mS after the first output the CM will produce another output (off) to
deactivate the Hazard Light circuit. This should result in a single parking light flash, but if there are no
flashes or too many flashes you will have to try the other options.
4-07 Parking light flash interval: Applicable to Hazard Light POC SV23 and POC SV30. This feature offers
optional parking light flash intervals during remote start when using a Hazard Light output
FO1- 10 seconds (default): With this option the CM will generate one parking light flash during remote
start every 10 seconds.
FO2- 20 seconds: With this option the CM will generate one parking light output during remote start
every 20 seconds.
FO3- 40 seconds: With this option the CM will generate one parking light output during remote start
every 40 seconds.
FO4- 60 seconds (1 min): With this option the CM will generate one parking light output during remote
start every 60 seconds.
4-08 Sliding door control for datalink: (must be enabled to allow data to data sliding door control) This
feature will provide an Unlock or Factory Alarm Disarm (FAD) output when triggering the AUX
control using iDatalink Modules (Sliding Doors)
FO1 - Off: (default) This option does not provide an unlock or a FAD output when activating AUX
output control using the iDatalink modules.
FO2 - Unlock and FAD: This option will provide unlock and a FAD output when activating AUX
output control using iDatalink modules.
FO3 - FAD only: This option will only provide a FAD (factory alarm disarms) output when activating
AUX output control using iDatalink modules.
4-09 PIC 4 (-) or (+) Door Input Polarity: This feature will allow the user to change the polarity input
ONLY for the red/white Door Input wire CN4 PIN 10. When using the default (-) Negative option
Red/White is a PIC.
FO1 – (-) Negative door input (default): This option will set the red/white wire for (-) negative input
as door input. It can be used for manual transmission or security to monitor the door zone/zones.
FO2 - (+) Positive door Input: This option will set the red/white wire for (+) positive input as a door
input. It can be used for manual transmission or security to monitor the door zone/zones
4-10 Positive Input Channel (+): (Positive input Channel 4 CN5 pin 14 Pink) this feature will determine
the input function of the PINK positive input wire
FO1 - Trigger start input: This option will enable PIC4 to be used as a trigger for activating the
remote start function using a (+) pulse input on the Pink wire CN5
FO2 – Ignition input: This option will enable PIC4 to be used as a B+ Ignition input only and be used
for any application where ignition output is not required. Including remote programming or Ignition
controlled door locks
FO3 - (+) keysense input: this option will operate as a key sense INPUT to the CM. When used with
manual transmission, keysense input will keep the CM from completing reservation mode as long as
the input is present. In addition, the keysense input will keep the system from passively arming or
RFID proximity locking as long as the input is present.
