11
UNPACKING AND HANDLING
After checking the countertops for level and
before sliding the range into place, measure
the distance from the floor to the top of the
counter work surface in the rear left and
right corners. Adjust the corresponding rear
corner of the range to an equal height of the
counter, as the rear leveling legs are not
accessible once the range is pushed into
place. Once the range is in place, the front
leg levelers can be accessed to level the
front of the range. Replace the kick panel
and oven doors by reversing the procedure
described previously. It is important that
the two screws retaining the kick panel are
secure to prevent accidental access to live
electrical components and wires (fig. 2
pg. 6).
GRIDDLE LEVEL ADJUSTMENTS
The grill and griddle sections (if equipped)
are fastened in place at the front with screws.
They are designed to be stationary and not
meant to be removed for cleaning. The
griddle has two leveling screws beneath the
rear flue cover which can be used to adjust
the griddle to the desired slope. To access
the leveling adjustment screws, remove the
griddle flue cover by lifting upwards. The
center screw is for shipping and should be
removed.
Fig. 7
Shipping Screw
(remove)
Outer Leveling
Screws (2)
Griddle Flue
Cover
