Fisher & Paykel OR36SDBGX1 User Manual

22
e
CORRECT POSITION OF DUAL BURNER
The DUAL burner must be correctly positioned (see fig. 5.6); the burner rib must be
fitted as shown by the arrows.
Position the central small cap in its housing as shown by the arrows (fig. 5.7).
Position the big cap in its housing as shown by the arrows (fig. 5.8).
IMPORTANT: NEVER unscrew the burner screws (fig. 5.9).
Fig. 5.8
Fig. 5.9
Fig. 5.6
Fig. 5.7
GAS VALVES
In the event of operating faults in the gas valves, call the Service Department.
5
