23
OVEN ACCESSORIES INSTALLATION AND REMOVAL
– Hang up the wire racks “G” on the oven walls (fig. 5.10).
– Slide in, on the guides, the shelves (fig. 5.11). Do not use the first step from the top.
The rack must be fitted so that the safety catch, which stops it sliding out, faces the
inside of the oven.
– Position the broiling pan above the oven shelf (see page 18).
– To dismantle, operate in reverse order.
STORAGE COMPARTMENT
The storage compartment is accessible
through the pivoting panel (fig. 5.13).
OVEN DOOR
The internal glass panel can be easily
removed for cleaning by unscrewing the
retaining screws (Fig. 5.12)
WARNING!!
Do not store flam-
mable material in the oven or in the
storage compartment.
Fig. 5.10
G
e
Fig. 5.12
Fig. 5.13
Do not use this step
Safety catch
Fig. 5.11
5
