133 Series
11
bolt circle in the mounting plate adaptor (key 56)
must be spaced (aligned) an equal distance over
the downstream control line connection. Install cap
screws and hex nuts (keys 35 and 36) with a torque
of 20 to 30 ft-lbs / 27 to 41 N•m.
7. Place the balancing plate washer (key 23),
balancing diaphragm plate (key 21), balancing
diaphragm (key 22) and a second balancing plate
washer (key 23), onto the stem (key 18).
Note
When installing the balancing diaphragm
(key 22), be certain the side marked
PISTON SIDE is facing the spring case.
Carefully tuck the slack diaphragm
material into the space between the
diaphragm plate (key 21) and lower
casing (key 7) until the diaphragm
ts smoothly over the diaphragm
plate without wrinkles and the bead
ts snugly and evenly in the groove
provided in the lower casing. This can
be done with a small screw screwdriver,
but be careful not to puncture the
diaphragm (see Figure 6).
8. Apply Multi-Purpose PTFE lubricant or equivalent
to the sealing washer (key 17) and carefully slide
over the threaded end of the stem (key 18).
9. Insert the guide bushing (key 24) into the cage
(key 5) and slide the cage up onto the stem
(key 18). Insert the set screws (key 39) only far
enough to retain the cage. Do not tighten.
10. Lubricate and install the O-rings (keys 19 and 4) as
indicated in Figure 14. Install the orice (key 2) onto
the cage (key 5). Install the Belleville spring washer
(key 3) so that the concave face of the washer
faces away from the orice.
11. Install the E-ring (key 26) on the stem sleeve
(key 25) and slide the stem sleeve over the stem
(key 18) aligning the slotted end of the stem sleeve
so that the roll pin (key 27) can be inserted through
the cross-drilled hole in the end of the stem.
CAUTION
Always use the stem sleeve wrench
ats when loosening or tightening the
nuts (key 20 or 31) to prevent twisting
of the main and balancing diaphragms
(keys 15 and 22).
12. Install the valve disk (key 28), registration disk
(key 29), washer (key 30) and hex nut (key 31)
onto the stem. The registration disk (key 29) is
marked for proper placement; be certain it is
positioned correctly on the stem (key 18). Tighten
the hex nut (key 31) using the 1/2 in. / 13 mm
wrench ats on the stem sleeve.
13. Insert the valve trim assembly into the body
and position the downstream control line
connection (key 51) so it is pointing directly
over the body outlet.
14. Screw the studs (key 33) into the body (key 1).
Install and tighten the hex nuts (key 34) to
20 to 35 ft-lbs / 27 to 47 N•m of torque.
15. Apply anti-seize to the adjusting screw (key 11)
and upper spring seat (key 41). Install the
adjusting screw and hex jam nut (key 59) into the
spring case (key 8). Position the control spring
(key 12) and upper spring seat on the diaphragm
plate (key 14) and lower spring seat (key 13).
16. Install the mounting plate gasket (key 57) and
place the spring case on the mounting bracket
(key 56). Install the cap screws (key 62) and
torque to 20 to 30 ft-lbs / 27 to 41 N•m.
17. Screw in the pipe nipple (key 49) and vent
(key 50). Install the closing cap gasket (key 10)
and closing cap (key 9).
Parts Ordering
When corresponding with your local Sales Ofce about
this equipment, be sure to include the type number and
other information stamped on the nameplate.
When ordering replacement parts, reference the key
number of each needed part and specify the eleven
character part number as found in the following parts list.
Parts List
Key Description Part Number
Parts kit for Types 133H, 133L and 133Z
(included are keys 2, 4, 6, 10, 15, 17, 19, 22,
24, 28, 32 and 40) R133HX00012
1 Body
Cast iron
2 NPT 30A3044X012
NPS 2 / DN 50, CL125 FF 30A3045X012
WCC Steel
2 NPT 30B0855X012
NPS 2 / DN 50, CL150 RF 30B0854X012
