Instruction Manual
D103626X012
685 Piston Actuator
June 2017
5
Table 5. Approximate Weights for Constructions with Handwheels
MAXIMUM
VALVE TRAVEL
APPROXIMATE WEIGHT FOR ACTUATOR SIZE, kg (lbs)
mm (inches) 12 14 16 18 20 22 24 26
102 (4.00) 591 (1304) 664 (1463) 834 (1838) 925 (2038)
203 (8.00) 622 (1372) 696 (1535) 873 (1924) 965 (2128)
305 (12.00) 226 (499) 363 (800) 292 (643) 454 (1000) 653 (1440) 729 (1607) 912 (2010) 1006 (2218)
406 (16.00) 239 (527) 380 (838) 311 (686) 474 (1046) 684 (1508) 762 (1679) 951 (2096) 1047 (2308)
508 (20.00) 252 (555) 397 (876) 331 (729) 495 (1092) 715 (1576) 794 (1751) 990 (2182) 1088 (2398)
610 (24.00) 264 (583) 415 (914) 350 (773) 516 (1138) 746 (1644) 827 (1823) 1029 (2268) 1129 (2488)
Table 6. Lifting Point Load Ratings
ACTUATOR SIZE
LIFTING
ORIENTATION
NUMBER OF LIFTING POINTS USED
MAXIMUM LOAD
kg lbs
12 to 24
Actuator Centerline
Horizontal
2 1540 3400
26 2 2860 6300
12 to 24
Actuator Centerline
Vertical
2 3760 8300
26 2 6350 14000
Installation
WARNING
Always wear protective gloves, clothing, and eyewear when performing any installation operations to avoid personal
injury.
To avoid personal injury or property damage caused by bursting of pressure‐retaining parts, be certain the cylinder
pressure or other pressure ratings do not exceed the limits listed in table 1. Use pressure‐limiting or pressure‐relieving
devices to prevent cylinder pressure or other pressures from exceeding these limits.
Check with your process or safety engineer for any additional measures that must be taken to protect against process
media.
If installing into an existing application, also refer to the WARNING at the beginning of the Maintenance section in this
instruction manual.
Dropping the actuator and any attached accessories and/or valve may cause personal injury and/or equipment damage. For
all mounting procedures use an adequately sized chain, sling, hoist, or crane to handle the actuator and any attached
accessories and/or valve. Use caution during lifting and handling to prevent slippage, swinging, faulty equipment
connections, or sudden shock loads.
CAUTION
Special care must be taken when installing an actuator in a horizontal service orientation. To avoid cantilever loads on the
valve stem and yoke, it is the customer’s responsibility to ensure proper support for a horizontal actuator.
When an actuator and control valve are shipped together as a control valve assembly, the actuator is normally
mounted on the valve. Follow the valve instructions when installing the valve in the pipeline. If the actuator is shipped
separately or if it is necessary to mount the actuator on the valve, perform the actuator mounting procedures in this
instruction manual. Refer to the individual product instruction manuals for the installation or mounting of a FIELDVUE
DVC6200 digital valve controller or 3610 positioner.
