Fisher 8560 - Page 32

Instruction Manual
D102013X012
8560 Valve
June 2017
32
Key Description Part Number
1‐1/4 inch 12A9138X012
1‐1/2 inch 12A9139X012
1‐3/4 inch 12A9140X012
111 Tag
114 Packing Follower
115* Packing Washer, Graphite Ribbon (3 req'd)
Key Description Part Number
1/2 inch 14A8362X012
5/8 inch 14A9771X012
3/4 inch 14A8363X012
1‐inch 14A8365X012
1‐1/4 inch 14A8366X012
1‐1/2 inch 14A8367X012
1‐3/4 inch 14A9772X012
Key 2*. Seal Retainer
VALVE STYLE VALVE SIZE, NPS
MATERIAL
Steel S31600 SST S31700 SST N08020 N10276 N04400
PTFE Seal Ring
Wafer
2 75B0385X012 75B0385X022 75B0385X042 75B0385X052 75B0385X062 75B0385X072
3 75B0019X012 75B0019X022 75B0019X032 75B0019X042 75B0019X062 75B0019X052
4 75B0041X012 75B0041X022 75B0041X032 75B0041X042 75B0041X062 75B0041X052
6 75B0002X012 75B0002X022 75B0002X032 75B0002X042 75B0002X062 75B0002X052
8 75B0010X012 75B0010X022 75B0010X032 75B0010X042 75B0010X062 75B0010X052
10 75B0027X012 75B0027X022 75B0027X032 75B0027X042 75B0027X062 75B0027X052
12 75B0034X012 75B0034X022 75B0034X032 75B0034X042 75B0034X062 75B0034X052
NOVEX and Phoenix III Seal Ring
Wafer
2 21B4667X012 21B4667X022 ‐ ‐ ‐ ‐ ‐ ‐ ‐ ‐ ‐ ‐ ‐ ‐
3 75B1040X012 75B1040X072 75B1040X082 ‐ ‐ ‐ ‐ ‐ ‐ ‐ ‐ ‐
4 75B1041X012 75B1041X072 75B1041X082 ‐ ‐ ‐ ‐ ‐ ‐ ‐ ‐ ‐
6 75B1042X012 75B1042X072 75B1042X082 ‐ ‐ ‐ ‐ ‐ ‐ ‐ ‐ ‐
8 75B1539X012 75B1539X022 75B1539X032 ‐ ‐ ‐ ‐ ‐ ‐ ‐ ‐ ‐
10 75B1540X012 75B1540X022 75B1540X032 ‐ ‐ ‐ ‐ ‐ ‐ ‐ ‐ ‐
12 75B1541X012 75B1541X022 75B1541X032 ‐ ‐ ‐ ‐ ‐ ‐ ‐ ‐ ‐
PTFE Seal Ring
Single Flange
3 75B0085X012 75B0085X022 75B0085X032 75B0085X042 75B0085X062 75B0085X052
4 75B0078X012 75B0078X022 75B0078X032 75B0078X042 75B0078X062 75B0078X052
6 75B0050X012 75B0050X022 75B0050X032 75B0050X042 75B0050X062 75B0050X052
8 75B0060X012 75B0060X022 75B0060X032 75B0060X042 75B0060X062 75B0060X052
10 75B0067X012 75B0067X022 75B0067X032 75B0067X042 75B0067X062 75B0067X052
12 75B0074X012 75B0074X022 75B0074X032 75B0074X042 75B0074X062 75B0074X052
NOVEX and Phoenix III Seal Ring
Single Flange
3 75B1047X132 75B1047X072 75B1047X082 ‐ ‐ ‐ ‐ ‐ ‐ ‐ ‐ ‐
4 75B1048X132 75B1048X072 75B1048X082 ‐ ‐ ‐ ‐ ‐ ‐ ‐ ‐ ‐
6 75B1049X132 75B1049X072 75B1049X082 ‐ ‐ ‐ ‐ ‐ ‐ ‐ ‐ ‐
8 75B1542X012 75B1542X022 75B1542X032 ‐ ‐ ‐ ‐ ‐ ‐ ‐ ‐ ‐
10 75B1543X012 75B1543X022 75B1543X032 ‐ ‐ ‐ ‐ ‐ ‐ ‐ ‐ ‐
12 75B1544X012 75B1544X022 75B1544X032 ‐ ‐ ‐ ‐ ‐ ‐ ‐ ‐ ‐
*Recommended spare parts
