Fisher EHD - Page 28

EH Valves (NPS 8 through 14)
Instruction Manual
April 2009
28
Key 3* Valve Plug for Valve without Whisper Trimr III Cage
VALVE SIZE,
NPS
VALVE
RATING
VALVE/PLUG
DESIGN
VALVE STEM
CONNECTION
SIZE
HEAT TREATED 420
STAINLESS STEEL
(EHD OR EHT)
316 STAINLESS STEEL WITH
ALLOY 6 (CoCr-A) SEAT AND GUIDE
For Use Only with
Cr Ct 316
Stainless Steel Cage
For Service Above
121_C (250_F)
mm Inches
8, 10
CL1500
EHD w/o
diverter cone
31.8
50.8
1-1/4
2
35A3998X012
35A3997X012
35A4001X012
35A4003X012
35A4002X012
35A4004X012
EHD
with diverter
cone
50.8 2 - - - 39A9047X012 39A9048X012
EHT w/o
diverter cone
31.8
50.8
1-1/4
2
35A3991X012
35A3992X012
35A4005X012
35A4007X012
35A4006X012
35A4008X012
EHT
with diverter
cone
50.8 2 - - - 39A9049X012 39A9050X012
CL2500
EHD w/o
diverter cone
31.8
50.8
1-1/4
2
35A3963X012
39A7494X012
35A3970X012
39A7495X012
35A3971X012
39A7496X012
EHD
with diverter
cone
50.8 2 - - - 39A9043X012 39A9044X012
EHT w/o
diverter cone
31.8
50.8
1-1/4
2
35A3962X012
39A7497X012
35A3968X012
39A7498X012
35A3969X012
39A7499X012
EHT
with diverter
cone
50.8 2 - - - 39A9045X012 39A9046X012
12, 14
CL1500
EHD w/o
diverter cone
31.8
50.8
1-1/4
2
35A3926X012
35A3927X012
35A3937X012
35A3939X012
35A3938X012
35A3940X012
EHD
with diverter
cone
50.8 2 - - - 39A9051X012 39A9052X012
EHT w/o
diverter cone
31.8
50.8
1-1/4
2
35A3924X012
35A3925X012
35A3935X012
35A3941X012
35A3936X012
35A3942X012
CL2500
EHT
with diverter
cone
50.8 2 - - - 39A9053X012 39A9054X012
EHD w/o
diverter cone
31.8
50.8
1-1/4
2
35A3998X012
35A3997X012
35A4001X012
35A4003X012
35A4002X012
35A4004X012
EHD
with diverter
cone
50.8 2 - - - 39A9047X012 39A9048X012
EHT w/o
diverter cone
31.8
50.8
1-1/4
2
35A3991X012
35A3992X012
35A4005X012
35A4007X012
35A4006X012
35A4008X012
EHT
with diverter
cone
50.8 2 - - - 39A9049X012 39A9050X012
*Recommended spare parts
