Fisher EHD - Page 29

EH Valves (NPS 8 through 14)
Instruction Manual
April 2009
29
Key 3* Valve Plug for NPS 8 or 10 Fisherr EHD with Whisper Trimr III Cage
MATERIAL
OPERATING
TEMPERATURE
LIMITS
VALVE
STEM
CONNEC-
TION
VALVE RATING
CL1500 CL2500
_C _F
mm Inches Level A, B, or C Level D Level A, B, or C Level D
17-4PH stainless steel,
H900 heat-treated
29 to 427 20 to 800
31.8 1-1/4 - - - 39A9122X012 - - - 39A9137X012
50.8 2 - - - 39A9124X012 - - - 39A9139X012
316 stainless steel, alloy 6 (CoCr-A)
seat and guide
29 to 149 20 to 300
31.8 1-1/4 39A9130X012 39A9126X012 39A9145X012 39A9141X012
50.8 2 39A9132X012 39A9128X012 39A9147X012 39A9143X012
93 to 204 200 to 400
31.8 1-1/4 39A9130X022 39A9126X022 39A9145X022 39A9141X022
50.8 2 39A9132X022 39A9128X022 39A9147X022 39A9143X022
149 to 260 300 to 500
31.8 1-1/4 39A9130X032 39A9126X032 39A9145X032 39A9141X032
50.8 2 39A9132X032 39A9128X032 39A9147X032 39A9143X032
204 to 316 400 to 600
31.8 1-1/4 39A9130X042 39A9126X042 39A9145X042 39A9141X042
50.8 2 39A9132X042 39A9128X042 39A9147X042 39A9143X042
260 to 371 500 to 700
31.8 1-1/4 39A9130X052 39A1926X052 39A9145X052 39A9141X052
50.8 2 39A9132X052 39A9128X052 39A9147X052 39A9143X052
316 to 427 600 to 800
31.8 1-1/4 39A9130X062 39A9126X062 39A9145X062 39A9141X062
50.8 2 39A9132X062 39A9128X062 39A9147X062 39A9143X062
371 to 482 700 to 900
31.8 1-1/4 39A9130X072 39A9126X072 39A9145X072 39A9141X072
50.8 2 39A9132X072 39A9128X072 39A9147X072 39A9143X072
427 to 538 800 to 1000
31.8 1-1/4 39A9130X082 39A9126X082 29A9145X082 39A9141X082
50.8 2 39A9132X082 39A9128X082 39A9147X082 39A9143X082
482 to 593 900 to 1100
31.8 1-1/4 39A9130X092 39A9126X092 39A9145X092 39A9141X092
50.8 2 39A9132X092 39A9128X092 39A9147X092 39A9143X092
N06600, alloy 6 (CoCr-A) seat
and guide
29 to 232 20 to 450
31.8 1-1/4 39A9130X102 39A9126X102 39A9145X102 39A9141X102
50.8 2 39A9132X102 39A1928X102 39A9147X102 39A9143X102
233 to 427 451 to 800
31.8 1-1/4 39A9130X112 39A9126X112 39A9145X112 39A9141X112
50.8 2 39A9132X112 39A9128X112 39A9147X112 39A9143X112
428 to 593 801 to 1100
31.8 1-1/4 39A9130X122 39A9126X122 39A9145X122 39A9141X122
50.8 2 39A9132X122 39A9128X122 39A9147X122 39A9143X122
17-4 stainless steel, H1150 heat-
treated, alloy 6 (CoCr-A) seat
and guide
29 to 427 20 to 800
31.8 1-1/4 39A9130X132 39A9126X132 39A9145X132 39A9141X132
50.8 2 39A9132X132 39A9128X132 39A9147X132 39A9143X132
17-4 stainless steel, H1150 DBL heat-
treated, alloy 6 (CoCr-A) seat and
guide, for sour gas service
29 to 232 20 to 450
31.8 1-1/4 39A9130X142 39A9126X142 39A9145X142 39A9141X142
50.8 2 39A9132X142 39A9128X142 39A9147X142 39A9143X142
*Recommended spare parts
