Key 3* Valve Plug for NPS 12 or 14 Fisherr EHD with Whisper Trimr III Cage
MATERIAL
OPERATING
TEMPERATURE
LIMITS
VALVE
STEM
CONNEC-
TION
VALVE RATING
CL1500 CL2500
_C _F
mm Inches Level A, B, or C Level D Level A, B, or C Level D
17-4PH stainless steel,
H900 heat-treated
29 to 427 20 to 800
31.8 1-1/4 - - - 39A9151X012 - - - 39A9122X012
50.8 2 - - - 39A9153X012 - - - 39A9124X012
316 stainless steel, alloy 6 (CoCr-A)
seat and guide
29 to 149 20 to 300
31.8 1-1/4 39A9159X012 39A9155X012 39A9130X012 39A9126X012
50.8 2 39A9161X012 39A9157X012 39A9132X012 39A9128X012
93 to 204 200 to 400
31.8 1-1/4 39A9159X022 39A9155X022 39A9130X022 39A9126X022
50.8 2 39A9161X022 39A9157X022 39A9132X022 39A9128X022
149 to 260 300 to 500
31.8 1-1/4 39A9159X032 39A9155X032 39A9130X032 39A9126X032
50.8 2 39A9161X032 39A9157X032 39A9132X032 39A9128X032
204 to 316 400 to 600
31.8 1-1/4 39A9159X042 39A9155X042 39A9130X042 39A9126X042
50.8 2 39A9161X042 39A9157X042 39A9132X042 39A9128X042
260 to 371 500 to 700
31.8 1-1/4 39A9159X052 39A1955X052 39A9130X052 39A9126X052
50.8 2 39A9161X052 39A9157X052 39A9132X052 39A9128X052
316 to 427 600 to 800
31.8 1-1/4 39A9159X062 39A9155X062 39A9130X062 39A9126X062
50.8 2 39A9161X062 39A9157X062 39A9132X062 39A9128X062
371 to 482 700 to 900
31.8 1-1/4 39A9159X072 39A9155X072 39A9130X072 39A9126X072
50.8 2 39A9161X072 39A9157X072 39A9132X072 39A9128X072
427 to 538 800 to 1000
31.8 1-1/4 39A9159X082 39A9155X082 29A9130X082 39A9126X082
50.8 2 39A9161X082 39A9157X082 39A9132X082 39A9128X082
482 to 593 900 to 1100
31.8 1-1/4 39A9159X092 39A9155X092 39A9130X092 39A9126X092
50.8 2 39A9161X092 39A9157X092 39A9132X092 39A9128X092
N06600, alloy 6 (CoCr-A) seat
and guide
29 to 232 20 to 450
31.8 1-1/4 39A9159X102 39A9155X102 39A9130X102 39A9126X102
50.8 2 39A9161X102 39A1957X102 39A9132X102 39A9128X102
233 to 427 451 to 800
31.8 1-1/4 39A9159X112 39A9155X112 39A9130X112 39A9126X112
50.8 2 39A9161X112 39A9157X112 39A9132X112 39A9128X112
428 to 593 801 to 1100
31.8 1-1/4 39A9159X122 39A9155X122 39A9130X122 39A9126X122
50.8 2 39A9161X122 39A9157X122 39A9132X122 39A9128X122
17-4 stainless steel, H1150 heat-
treated, alloy 6 (CoCr-A) seat
and guide
29 to 427 20 to 800
31.8 1-1/4 39A9159X132 39A9155X132 39A9130X132 39A9126X132
50.8 2 39A9161X132 39A9157X132 39A9132X132 39A9128X132
17-4 stainless steel, H1150 DBL heat-
treated, alloy 6 (CoCr-A) seat and
guide, for sour gas service
29 to 232 20 to 450
31.8 1-1/4 39A9200X012 39A9196X012 39A9130X142 39A9126X142
50.8 2 39A9202X012 39A9198X012 39A9132X142 39A9128X142
*Recommended spare parts
