Fisher EHD - Page 31

EH Valves (NPS 8 through 14)
Instruction Manual
April 2009
31
Key 3* Valve Plug for Fisherr EHT with Whisper Trimr III Cage
VALVE
SIZE,
NPS
MATERIAL
OPERATING
TEMPERATURE
LIMITS
VALVE
STEM
CONNEC-
TION
VALVE RATING
CL1500 CL2500
_C _F
mm Inches Level A, B, or C Level D Level A, B, or C Level D
8, 10
17-4 stainless steel,
H1075 heat-treated
29 to 232 20 to 450
31.8 1-1/4 - - - 39A9123X012 - - - 39A9138X012
50.8 2 - - - 39A9125X012 - - - 39A9140X012
316 stainless steel, alloy 6
(CoCr-A) seat and guide
29 to 149 20 to 300
31.8 1-1/4 39A9131X012 39A9127X012 39A9146X012 39A9142X012
50.8 2 39A9133X012 39A9129X012 39A9148X012 39A9144X012
93 to 204 200 to 400
31.8 1-1/4 39A9131X022 39A9127X022 39A9146X022 39A9142X022
50.8 2 39A9133X022 39A9129X022 39A9148X022 39A9144X022
149 to 232 300 to 450
31.8 1-1/4 39A9131X032 39A9127X032 39A9146X032 39A9142X032
50.8 2 39A9133X032 39A9129X032 39A9148X032 39A9144X032
N06600, alloy 6 (CoCr-A)
seat and guide
29 to 232 20 to 450
31.8 1-1/4 39A9131X042 39A9127X042 39A9146X042 39A9142X042
50.8 2 39A9133X042 39A9129X042 39A9148X042 39A9144X042
17-4 stainless steel, H1150
heat-treated, alloy 6
(CoCr-A) seat and guide
29 to 232 20 to 450
31.8 1-1/4 39A9131X052 39A9127X052 39A9146X052 39A9142X052
50.8 2 39A9133X052 39A9129X052 39A9148X052 39A9144X052
17-4 stainless steel, H1150
DBL heat-treated, alloy 6
(CoCr-A) seat and guide, for
sour gas service
29 to 149 20 to 300
31.8 1-1/4 39A9131X062 39A9127X062 39A9146X062 39A9142X062
50.8 2 39A9133X062 39A9129X062 39A9148X062 39A9144X062
12, 14
17-4 stainless steel,
H900 heat-treated
29 to 232 20 to 450
31.8 1-1/4 - - - 39A9152X012 - - - 39A9123X012
50.8 2 - - - 39A9154X012 - - - 39A9125X012
316 stainless steel, alloy 6
(CoCr-A) seat and guide
29 to 149 20 to 300
31.8 1-1/4 39A9160X012 39A9156X012 39A9131X012 39A9127X012
50.8 2 39A9162X012 39A9158X012 39A9133X012 39A9129X012
93 to 204 200 to 400
31.8 1-1/4 39A9160X022 39A9156X022 39A9131X022 39A9127X022
50.8 2 39A9162X022 39A9158X022 39A9133X022 39A9129X022
149 to 232 300 to 450
31.8 1-1/4 39A9160X032 39A9156X032 39A9131X032 39A9127X032
50.8 2 39A9162X032 39A9158X032 39A9133X032 39A9129X032
N06600, alloy 6 (CoCr-A)
seat and guide
29 to 232 20 to 450
31.8 1-1/4 39A9160X042 39A9156X042 39A9131X042 39A9127X042
50.8 2 39A9162X042 39A9158X042 39A9133X042 39A9129X042
17-4 stainless steel, H1150
heat-treated, alloy 6
(CoCr-A) seat and guide
29 to 232 20 to 450
31.8 1-1/4 39A9160X052 39A9156X052 39A9131X052 39A9127X052
50.8 2 39A9162X052 39A9158X052 39A9133X052 39A9129X052
17-4 stainless steel, H1150
DBL heat-treated, alloy 6
(CoCr-A) seat and guide, for
sour gas service
29 to 149 20 to 300
31.8 1-1/4 39A9201X012 39A9197X012 39A9131X062 39A9127X062
50.8 2 39A9203X012 39A9199X012 39A9133X062 39A9129X062
*Recommended spare parts
