Key 6* Seat Ring and Key 7 Cap Screw for Valve with Gasket Construction and without Whisper Trimr III Cage
VALVE
SIZE,
NPS
MATERIAL
VALVE
RATING
KEY 6
SEAT RING
KEY 7 CAP SCREW
Seat Ring Cap Screw Part Number
Quantity
Required
8, 10
17-4PH stainless steel,
H1075 heat-treated
SA-564,
H1100 heat-treated
CL1500 39A7400X032 19A7492X022
22
CL2500 39A7402X032 19A7493X022
N07718 SB-637, GR 718
CL1500 39A7400X022 19A7492X012
CL2500 39A7402X022 19A7493X012
316 stainless steel, alloy 6 (CoCr-A)
seat
SA-453-660,
CLA
CL1500 39A7401X032 19A7492X032
CL2500 39A7403X032 19A7493X032
N06600, alloy 6 (CoCr-A) seat SB-637, GR 718
CL1500 39A7401X042 19A7492X012
CL2500 39A7403X042 19A7493X012
12, 14
17-4PH stainless steel,
H1075 heat-treated
SA-564,
H1100 heat-treated
CL1500 39A7404X032 19A7493X022
28
CL2500 39A7406X032 19A7493X022
N07718 SB-637, GR 718
CL1500 39A7404X022 19A7493X012
CL2500 39A7406X022 19A7493X012
316 stainless steel, alloy 6 (CoCr-A)
seat
SA-453-660,
CLA
CL1500 39A7405X032 19A7493X032
CL2500 39A7407X032 19A7493X032
N06600, alloy 6 (CoCr-A) seat SB-637, GR 718
CL1500 39A7405X042 19A7493X012
CL2500 39A7407X042 19A7493X012
*Recommended spare parts
