Fisher EHD - Page 36

EH Valves (NPS 8 through 14)
Instruction Manual
April 2009
36
Key 6* Seat Ring and Key 7 Cap Screw for Valve with Gasket Construction and Whisper Trimr III Cage
VALVE
SIZE,
NPS
MATERIAL
VALVE
RATING
KEY 6
SEAT RING
KEY 7 CAP SCREW
Part Number
Quantity
Required
Seat Ring Cap Screw
8, 10
17-4PH stainless steel,
H1075 heat-treated
SA-564,
H1100 heat-treated
CL1500 39A7400X032 19A7492X022
22
CL2500 39A7402X032 19A7493X022
17-4PH stainless steel,
H1150 heat treated,
alloy 6 (CoCr-A) seat
SA-564,
H1100 heat-treated
CL1500 39A7401X122 19A7492X022
CL2500 39A7403X122 19A7493X022
316 stainless steel, alloy 6
(CoCr-A) seat, for
temperatures up to 260_C (500_F)
SA-453-660,
CLA
CL1500 39A7401X032 19A7492X032
CL2500 39A7403X032 19A7493X032
316 stainless steel, alloy 6
(CoCr-A) seat, for
temperatures up to 427_C (800_F)
SA-453-660,
CLA
CL1500 39A7401X062 19A7492X032
CL2500 39A7403X062 19A7493X032
316 stainless steel, alloy 6
(CoCr-A) seat, for
temperatures up to 593_C (1100_F)
SA-453-660,
CLA
CL1500 39A7401X082 19A7492X032
CL2500 39A7403X082 19A7493X032
N06600, alloy 6
(CoCr-A) seat, for
temperatures up to 427_C (800_F)
SB-637, GR 718
CL1500 39A7401X042 19A7492X012
CL2500 39A7403X042 19A7493X012
N06600, alloy 6
(CoCr-A) seat, for
temperatures up to 593_C (1100_F)
SB-637, GR 718
CL1500 39A7401X102 19A7492X012
CL2500 39A7403X102 19A7493X012
N07718, heat-treated SB-637, GR 718
CL1500 39A7400X022 19A7492X012
CL2500 39A7402X022 19A7493X012
12, 14
17-4PH stainless steel,
H1075 heat-treated
SA-564,
H1100 heat-treated
CL1500 39A9009X022 19A7493X022
28
CL2500 39A7406X032 19A7493X022
17-4PH stainless steel,
H1150 heat treated,
alloy 6 (CoCr-A) seat
SA-564,
H1100 heat-treated
CL1500 39A9010X122 19A7493X022
CL2500 39A7407X122 19A7493X022
316 stainless steel, alloy 6
(CoCr-A) seat, for
temperatures up to 260_C (500_F)
SA-453-660,
CLA
CL1500 39A9010X022 19A7493X032
CL2500 39A7407X032 19A7493X032
316 stainless steel, alloy 6
(CoCr-A) seat, for
temperatures up to 427_C (800_F)
SA-453-660,
CLA
CL1500 39A9010X042 19A7493X032
CL2500 39A7407X062 19A7493X032
316 stainless steel, alloy 6
(CoCr-A) seat, for
temperatures up to 593_C (1100_F)
SA-453-660,
CLA
CL1500 39A9010X062 19A7493X032
CL2500 39A7407X082 19A7493X032
N06600, alloy 6
(CoCr-A) seat, for
temperatures up to 427_C (800_F)
SB-637, GR 718
CL1500 39A9010X082 19A7493X012
CL2500 39A7407X042 19A7493X012
N06600, alloy 6
(CoCr-A) seat, for
temperatures up to 593_C (1100_F)
SB-637, GR 718
CL1500 39A9010X102 19A7493X012
CL2500 39A7407X102 19A7493X012
N07718, heat-treated SB-637, GR 718
CL1500 39A9009X032 19A7493X012
CL2500 39A7406X022 19A7493X012
*Recommended spare parts
