Fisher FIELDVUE DVC2000 Instruction Manual Supplement

Instruction Manual Supplement
D103783X012
DVC2000 Digital Valve Controller
September 2017
3
Reference Documentation
HART Smart Communications Protocol Specification Revision 5; a group of documents specifying the HART
Communication Protocol, physical layers, and Data Link Layers as defined by the HART Communications Foundation.
Bulletin 62.1:DVC2000 Fisher FIELDVUE DVC2000 Digital Valve Controller (D103167X012
)
Fisher FIELDVUE DVC2000 Digital Valve Controllers Quick Start Guide (D103203X012
)
Fisher FIELDVUE DVC2000 Digital Valve Controller Instruction Manual (D103176X012
)
Device Identification
Manufacturer Name Fisher Controls Model Name(s) DVC2000
Manufacture ID Code 19 (13 Hex) Device Type Code 5 (05 Hex)
HART Protocol Revision 5 Device Revision 1
User Selectable HART Revision
between HART 5 and HART 7
No
Number of Device Variables 8
Physical Layers Supported FSK
Physical Device Category Valve Positioner

Fisher FIELDVUE DVC2000 Specifications

General

Manufacturer	Fisher
Category	Controller
Device Type	Digital Valve Controller
Communication Protocol	HART
Input Signal	4-20 mA
Enclosure Rating	NEMA 4X, IP66
Operating Temperature	-40 to 85°C (-40 to 185°F)
Material	Aluminum
Power Supply	Loop Powered
Diagnostics	Advanced diagnostics
Output Signal	4-20 mA
Certifications	ATEX, IECEx, CSA, FM
Mounting	Integral mounting to actuator
