Instruction Manual Supplement
D103797X012
DVC6200 Series Approval Nameplates
December 2014
12
Figure 35. IECEx Approvals Nameplate for DVC6200p, DVC6205p
Figure 36. INMETRO Approvals Nameplate for DVC6200p, DVC6205p
Figure 37. KGS Approvals Nameplate for DVC6200p, DVC6205p
Figure 38. Customs Union Approvals Nameplate for DVC6200p, DVC6205p

Table of Contents

Questions and Answers:

Question and Answer IconNeed help?

Do you have a question about the Fisher FIELDVUE DVC6200 HW1 and is the answer not in the manual?

Fisher FIELDVUE DVC6200 HW1 Specifications

General IconGeneral
Communication ProtocolHART
Operating Temperature Range-40 to 85 °C (-40 to 185 °F)
Enclosure RatingNEMA 4X, IP66
ManufacturerFisher
ModelDVC6200
TypeDigital Valve Controller
Power SupplyLoop powered
Hazardous Area CertificationsATEX, IECEx, FM, CSA
HW RevisionHW1
Ambient Temperature Range-40 to 85°C (-40 to 185°F)
Input Signal4-20 mA, HART
DiagnosticsAdvanced diagnostics
Output Signal4-20 mA
CertificationsATEX, IECEx, FM, CSA
