Fishman Aura User Manual

Aura
™
Acoustic Imaging Blender
30
Specifications
Power: 150 mA @ 9Vdc
Power Connection: Center pin negative
2.1mm dia., 5.5mm outer dia.
Input Impedance: 5 Meg
Output Impedance: 1k
Nominal Operating Level: -17dBu
Unbalanced Output Level: -10dBu +/- 2dB (-10dBu, 1kHz input)
Balanced Output Level: -4dBu +/- 2dB (-10dBu, 1kHz input)
Distortion: Less than 0.1% w/ 30kHz LPF filter
(-10dBu, 1kHz input)
Noise Level: -74dBu, 20Hz - 20kHz A-weighted
Frequency response: 20Hz: 0 +/- 2dB,
20kHz:-1.5 +/- 2dB
Level Indicator Thresholds: Red (High): -11 dBu +/- 2dB
Yellow (Mid): -17 dBu +/- 2dB
Green (Low): -24 dBu +/-2dB
Digital Sound Image Bass: Normalizes level when boosting bass -
baseline gain drops 4 dB at maximum
bass boost
Boost: +11.5dB @ 20Hz (relative to 2kHz)
+10dB @ 60Hz (relative to 2kHz)
+8dB @ 100Hz (relative to 2kHz)
+3dB @ 300Hz (relative to 2kHz)
Cut: -9dB @ 20Hz
-8.4 dB @ 60Hz
-7dB @ 100Hz
-3dB @ 300Hz
Pickup Bass:
Boost: +11.5db @ 20Hz
+10dB @ 60Hz
+8dB @ 100Hz
+3dB @ 300Hz
Cut: -9dB @ 20Hz
-8.4 dB @ 60Hz
-7dB @ 100Hz
-3dB @ 300Hz
Digital Sound Image & Pickup Treble Controls:
Boost: +12dB @ 20kHz
+9 dB @ 10kHz
+3dB @ 3kHz
Cut: -9dB @ 20kHz
-8dB @ 10kHz
-3dB @ 3kHz
Digital Sound Image & Pickup Mid Controls:
Boost: +11.5dB
Cut: -9dB
Center Frequency: 1kHz
Bandwidth: 0.55 octave
(full boost, -3dB from peak)
Specifications
Anti-Feedback Filter:
Cut: -14 dB
Bandwidth: 0.25 octave (-3dB from baseline gain)
Default Frequency: 100Hz (Without running “Measure”
calibration)
Compressor
C1-C9: Chord/strumming style
Sustained with smooth attack
L1-L9: Lead style
Percussive attack characteristic
Compression threshold: -22dBu
Compression attenuation at -10dBu:
1dB - 9dB corresponding to the
number in the selected compression
setting.
Example: C7 or L7 would produce a maximum
compression of 7dB.
Noise Gate: On when compression is selected.
Gate Threshold: -46dBu
Normalized Compressor Drive Gain:
To minimize shift in operating level,
mid level gain increases proportional
to each of the compression settings
All Specifications Subject to Change Without Notification
Appendix A

Fishman Aura Specifications

General

Brand	Fishman
Model	Aura
Category	Blender
Language	English
