7.3 Engage the tip locator arm by lifting
it 90º and lock it in place.
7.4 Use the thumb screw on the arm to
make micro height adjustments.
7.3
Tip Locator Arm
in locked postion.
7.4
Thumb Screw to
make micro
adjustments
