7.5 When adjusted, lock the thumb wheel
into place to capture the height. Gently
tug the tip locator arm to disengage
and remove the LDS dispense gun.
7.6 Add a second LDS dispense gun with
lled syringe and dispense tip and lock
the locator arm in place. If necessary, make
a slight adjustment to the luer lock dispense
tip until it comes into contact with the end
of the thumb screw.
Locator Arm
disengaged
Thumb Wheel
locked in place
