7.0 Dispense Tip Locator
7.1 If you are using a LDS dispense gun in an
automated environment, secure the Dispense
Tip Locator to the gun mount bracket with
the screws provided and follow these steps
before priming the dispense tip.
7.2 Adjust the thumb screw on the rail
to approximate the height of the LDS
dispense gun with lled syringe barrel
and dispense tip attached.
Tip Locator Arm
Thumb Screw to
adjust height
To Next Page
