Network
SmartDispenser
®
Components
A. LDS
TM
Push-to-
Connect
TM
Dispense Gun
B. Gun Connector
C. Foot Pedal
D. Foot Pedal
Connector
E. Keyboard
F. Mouse
G. USB connectors
H. Ethernet Port
I. Cisco Wireless
Connectivity
Device
J. Video Camera
K. Power Cord
L. Universal Power
Supply
M. Power Supply
Connector
N. On/Off Button
O. Power Light
P. Touch Screen
Q. Earphone
R. Earphone Port
