3.2 Plug SmartDispenser
®
Push-to-Connect
™
Gun
Mount
A
into gun connector
B
located on the
front of the SmartDispenser
®
.
3.3 Place the foot pedal
C
on the oor and plug it
into the foot pedal input connector
D
located
on the back of the SmartDispenser
®
.
3.4 Connect the system keyboard
E
and mouse
F
using one of the four USB connectors
G
located
on the front and back of the SmartDispenser
®
.
3.5 Connect your SmartDispenser
®
to an Ethernet
network using the Ethernet port
H
found on the
back of the unit. If you have a wireless network,
install the supplied wireless connectivity device
I
in one of the USB connectors
G
located on the
front and back of the unit. (Optional)
3.6 Plug the supplied video camera
J
into one of the
four USB connectors
G
located on the front and
back of the SmartDispenser
®
. (Optional)
3.7 Connect the power cord
K
to the universal
power supply
L
.
3.8 Connect the universal power supply
L
to the
power supply connector
M
on the back of the
SmartDispenser
®
. Plug the power cord
K
into
a power outlet.
3.9 Connect the 2.5mm earphone
Q
to earphone
port
R
. (Optional)
