SPECIFICATIONS
Nominal Input Level: -20 dBV
Input Overload: (20 Hz - 20 kHz)-2 dBV
Pickup Input Impedance: 20 M Ohms
Output Impedance (tip): Less than 3.5 k Ohms
Output Impedance (ring): Less than 6.6 k Ohms
Nominal Output Level (tip): -12 dBV
Output Level Range (ring): Max: -12 dBV Min: -16dBV
THD: Less than .04 %, -20 dBV input
Signal to Noise Ratio: 77 dB (A weighted referred to nominal
-20 dBV input)
Current Drain: Less than 4 mA
Power Supply: 9V alkaline battery (estimated 140 hours
continuous use with low battery indicator
at 6.5V)
Notch Filter Range: 20Hz - 300 Hz (-15 dB)
Bass Control Range:
±
12 dB at 60 Hz
±
3 dB at 350 Hz
Treble Control Range:
±
12 dB at 10 kHz
±
3 dB at 2.4 kHz
Contour Control Range:
±
12dB
(adjustable from 250 Hz to 10 kHz)
Q = 0.5
All specifications subject to change without notice.
11
11
U
U
SER
SER
G
G
UIDE
UIDE
PICKUP ONLY
