Quick Start Cont’d ...
4. Slowly increase the Volume again, until you start to hear a high squeal.
5. Lower the Contour Slider (level) all the way down and adjust the Frequency slid-
er until the squealy feedback is eliminated. Raise the Contour slider (if possible)
to just below the threshold of feedback.
6. Move the Blend slider to the right to mix in the pickup signal (B).
7. Adjust the Bass and Treble controls as desired. Note that these controls do not
affect the microphone signal.
8. Play your guitar as loud as you like.
See diagram on page 9
SETUP
Battery Compartment
Pull the small tab at the top of
the Onboard Blender™ toward
you. The body of the preamp
will swing out, revealing the
battery compartment. Observe
the polarity marks on the bat-
tery clip and install a fresh 9V
alkaline battery accordingly.
Microphone Trim Control
A small circular potentiometer is located on the underside of the preamp just below
the battery compartment. This is a "set it and forget it" control. Use it to initially cali-
brate the microphone balance in relation to the pickup. Set the Blend slider to the
center position and with a small slotted screwdriver, adjust the Trim Control until
both the microphone and pickup levels are balanced to your taste.
4
