XLR (BALANCED) OUT
Plug a standard XLR cable from your PA or recording console into this low
impedance balanced output. Note that the Pro EQ Platinum can run off 48-Volt
phantom power through this output. See Power section above for phantom
power operation.
OUTPUT (1/4" UNBALANCED)
Plug a standard instrument cable from this output to a stage amp or an unbal-
anced microphone input on a Mixer. All the Pro EQ Platinum's controls (except
the XLR switches) will affect this output.
TUNER/SEND
Use this output when you need an unbalanced fixed level signal (regardless of
changes in stage or house level), for an external tuner, recording device or a
live radio feed. The Tuner/Send output is affected only by the Pro EQ
Platinum's Input Gain control.
Using an Electronic tuner with the Tuner/Send
Run a ¼" instrument cable from the Tuner/Send to an electronic tuner. For
discrete tuning from stage, simply turn down the Volume control on the
Platinum.
Make a Recording off the Tuner/Send
Use the Tuner/Send as an auxiliary unbalanced fixed level send (into a sep-
arate direct box) for recording or broadcast gear. This output will stay
"live", regardless of changes to the house (XLR out, post EQ) or stage (1/4"
output) levels.
