8Page
1. Connect the AC power cord to the AC outlet.
2. The transit screw protects the phonograph chassis during transportation. If the speed of your
phonograph seems slow or you hear a rubbing sound, adjust the screw with a coin to correct
the balance of the turntable.
Preparation for Use
Removing old stylus
1. Set a screwdriver at the tip of the stylus and push down in the
direction “A”.
2. Remove the stylus by pulling it forward and down.
Installing a new stylus
1. Hold the tip of the stylus and insert the other edge by pressing in
the direction “B”.
2. Push up in the direction “C” until it locks at the tip.
How to replace the Turntable Stylus (Needle)
