CET.ACEC compact controller Technical description
FläktGroup DC-2017-0104-GB 2018-05/R1 • Subject to change 11
2.4.1 Accessories
Flow/inlet temperature sensor defective Type 903.434
Type series CET.ACEC
Optional accessories Sensor type 903.414
Mechanical data
External dimensions (W/H/D) 84 x 84 x 22 mm
Allowed ambient temperature -35 °C to 70 °C
Fixation on the wall
Weight 40 g
Casing color RAL 9010 (pure white)
Application position vertical
Protection type (according to DIN
40050)
IP20
Cable entry point Cable inlet from behind, for flush-mounted box
Electrical data
Resistance 10 kOhm/25 °C
VOLTAGE Max. 12 V
Optional accessories Sensor Type 903.434
Mechanical data
External dimensions of bulb 6 x 35 mm
Maximum ambient temperature 100 °C
Mounting on pipework
Weight 40 g
Casing color RAL 9010 (pure white)
for OP5I similar to RAL 7035 (light grey)
Application position arbitrary
Protection type (according to DIN
40050)
IP43
Cable length 2 m
Electrical data
Resistance 10 kOhm/25 °C
VOLTAGE Max. 12 V
