flamco Flamcomat MP G4 - Control Module External Pressure Retention, Manual Control Valve, Adjustment Values; Control Module External Pressure Retention, Top-Up, Flow Rate

Manual Flamcomat MP G4
We reserve the right to change designs and technical specifications of our products.
45
ENG
Control module external pressure retention, manual control valve, adjustment values
Setting values manual regulated valve M02 aer pump see paragrapgh “Component parts”, equipment [3,23].
Manual control valve
(Pos. 3.10; 3.11; page 19...21)
Version MP
(M M ÷ M130) - Valve 1,
Version DP
(D M ÷ D130) - Valve 1 and 2
Example
MP / DP 02-2-50 (M02/D02):
Operating pressure 3.8 bar
Control module external pressure retention, top-up, flow rate
Setting values
Operating pressure P
A
(bar)
M02 (9.9)
M02 (6.0)
M02 (4.5)
0
1
1,2
1,4
1,6
1,8
2,2
2,4
2,6
2,8
3,2
3,4
3,6
2
3
0,24 0,47 0,71 0,94 1,18 1,41 1,65 1,88 2,12 2,35
0 0,2 0,4 0,6 0,8 1 1,2 1,4 1,6 2,8 2
Operating pressure P
A
(bar)
Heating capacity [MW]
Nominal flow [m
3
/h]
Setting values
Operating pressure P
A
(bar)
2,3
