Manual Flamcomat MP G4
We reserve the right to change designs and technical specifications of our products.
48
ENG
Appendix 4.
MeiFlow L MF connector kit
The MeiFlow L MF Connector kit is used to easily connect the large distribution systems with pressure
maintenance/degassing machines by means of a BigFixLock adapter plate DN150 with 2 threaded connections (1
1/4” male). The connection pipe (provided by the customer) to the respective vending machine can be connected
to these sockets. The EPDM inliner is used to separate the flow rates of the machines.
Advantages
• Easy installation due to BigFixLock connection
• Predefined connection point to additional system components directly on the manifold beam.
• Additional filling and draining or sensor installation option.
Typ Connection Order code
MeiFlow L MF Connector Kit
DN 150
1 1/4“ 1 M66456.2
