FLARING FM 155E - Operating Instructions; Operation Panel Interface

- 10 -
3 operating instructions
3.1 Operation panel interface
1 Current display
：
Displays preset current and actual welding current.
2
MIG welding torch switch (Effective only in MIG 0.8/MAG 0.8/FLUX 1.0):The welding machine
only be operated with the Spool gun torch in the Spool gun torch mode; The MIG torch only be
used for welding in the MIG torch mode.Please check the switch status when using.
3 This light is on in Stick mode
4 This light is on in LIFT TIG mode
1
2
3
4
8
6
9
5
7
11
10
