FLARING FM 155E - Technical Parameters

- 4 -
1.2 Technical parameters
Machine type FM 155E
Supply voltage (V) 1 phase AC 110V/ 220V±15%
Frequency (Hz) 50/60
Rated Max. input
current (A)
110
29 (MIG)
36.7 (STICK)
21.4 (TIG)
220
20 (MIG)
27.4 (STICK)
16.7 (TIG)
Output current
adjustment (A)
110V
30-100 (MIG)
30-100 (STICK)
30-100 (TIG)
220V
30-150 (MIG)
30-150 (STICK)
30-150 (TIG)
Output voltage (V)
110V
15.5-19 (MIG)
21.2-24(STICK)
11.2-14 (TIG)
220V
15.5-21.5 (MIG)
21.2-26(STICK)
11.2-16 (TIG)
No load voltage (V)
50±5
Duty cycle (%) 80
Power factor 0.7
Efficiency (%) 85
Wire feeder type All-in-one
Wire feed speed
(m / min)
2-15
Wire diameter (mm) 0.8/1.0
Insulation grade F
Enclosure protection
class
IP21
Suitable plate
thickness (mm)
0.5-5
Net Weight (kg) 12.8
Overall dimension
(mm)
510
×
310
×
350
