Rotational laser
14
Technical specifications
* depending on the ambient light
Operating instructions
Before switching on the power
tool
Unpack the power tool and check that the
delivery is complete and not damaged.
Before using the power tool for the first time
– Insert the battery into the remote control,
– Insert batteries into the machine.
Mains mode
The machine can be used with a standard
power supply unit (6 V d.c., 2.5 mm jack
plug).
Connect the power supply unit to the socket
(15).
Using batteries in the power tool
Note
If the LED (3) flashes, replace the battery
set.
Required batteries:
– 4 x type AA / 1.5 V
n Open the battery compartment (14)
on the machine.
n Insert the batteries the correct way
round.
n Close the battery compartment.
Batteries for the remote control
Note
The button configuration on the remote control
corresponds to the buttons on the ALR.
The power tool can only be switched off with
the remote control.
Order number 311.294
Precision ±3 mm/10 m
Operating modes:
– Rotating laser beam (standard)
– Scan 1: line
– Scan 2: oscillating beam
– Point
– Additional: Vertical beam (hairline
function)
Range:
– rotating laser beam approx.
10 m*
– Point function approx.
30 m*
– Scan function approx.
20 m*
– Remote control approx.
50 m*
Speed of rotation 0–350/min
Operating time (batteries) ~18 h
Visible laser diode 635–670 nm
Laser class 2
Weight (ALR batteries) 0.87 kg
Laser_ALR411.book Seite 14 Donnerstag, 24. Februar 2005 9:42 09
